ISO B Series Hydraulic Quick-Connect Couplings

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a 0 Degrees F to 1292 Degrees F temperature range, and a 1/2-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from FKM.

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a 0 Degrees F to 1292 Degrees F temperature range, and a 1/2-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from FKM.

This quick coupling has a poppet-style valve, a 4060 PSI maximum working pressure, a 0 Degrees F to 1292 Degrees F temperature range, and a one-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from FKM.

This quick coupling has a poppet-style valve, a 4060 PSI maximum working pressure, a 0 Degrees F to 1292 Degrees F temperature range, and a one-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from FKM.

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 1/4-inch NPTF connection. This coupling is made from stainless steel and features a Viton seal and a locking sleeve.

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 1/4-inch NPTF connection. This coupling is made from stainless steel and features a Viton seal and a locking sleeve.

This plug has a 7250 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 1/8-inch NPTF connection. It has a Buna-N seal, a stainless steel bearing, a steel sleeve, and a zinc-plated finish.

This plug has a 7250 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 1/8-inch NPTF connection. It has a Buna-N seal, a stainless steel bearing, a steel sleeve, and a zinc-plated finish.

This hydraulic nipple has a 3,626 PSI maximum working pressure, a 3/4-inch NPT connection, and a 3/4-inch body size. This nipple features a poppet valve and a -40 Degrees F to 158 Degrees F temperature range. It has a zinc-plated steel sleeve, a stainless steel bearing, and a Buna-N seal.

This hydraulic nipple has a 3,626 PSI maximum working pressure, a 3/4-inch NPT connection, and a 3/4-inch body size. This nipple features a poppet valve and a -40 Degrees F to 158 Degrees F temperature range. It has a zinc-plated steel sleeve, a stainless steel bearing, and a Buna-N seal.

This hydraulic coupler has a 2,901 PSI maximum working pressure, a one-inch NPT connection, and a one-inch body size. This coupler features a poppet valve and a -40 Degrees F to 158 Degrees F temperature range. It has a zinc-plated steel sleeve, a stainless steel bearing, and a Buna-N seal.

This hydraulic coupler has a 2,901 PSI maximum working pressure, a one-inch NPT connection, and a one-inch body size. This coupler features a poppet valve and a -40 Degrees F to 158 Degrees F temperature range. It has a zinc-plated steel sleeve, a stainless steel bearing, and a Buna-N seal.

This plug has a 2611 PSI maximum working pressure and a -4 Degrees F to 392 Degrees F temperature range. This plug features a poppet valve and a 1/2-inch NPTF connection. It has a Viton seal, a stainless steel bearing, and a brass sleeve.

This plug has a 2611 PSI maximum working pressure and a -4 Degrees F to 392 Degrees F temperature range. This plug features a poppet valve and a 1/2-inch NPTF connection. It has a Viton seal, a stainless steel bearing, and a brass sleeve.

This quick coupling has a poppet-style valve, a 3625 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 3/8-inch NPTF connection. This coupling is made from stainless steel and features a Viton seal.

This quick coupling has a poppet-style valve, a 3625 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 3/8-inch NPTF connection. This coupling is made from stainless steel and features a Viton seal.

This plug has a 3625 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 3/4-inch NPTF connection. This stainless steel plug has a Viton seal.

This plug has a 3625 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 3/4-inch NPTF connection. This stainless steel plug has a Viton seal.

This plug has a 4350 PSI maximum working pressure and a -0 Degrees F to 1292 Degrees F temperature range. This plug features a poppet valve and a 3/4-inch NPTF connection. It has a FKM seal, a stainless steel bearing, a steel sleeve, and a zinc-plated finish.

This plug has a 4350 PSI maximum working pressure and a -0 Degrees F to 1292 Degrees F temperature range. This plug features a poppet valve and a 3/4-inch NPTF connection. It has a FKM seal, a stainless steel bearing, a steel sleeve, and a zinc-plated finish.

This dust cap and plug has a 3/8-inch body size and is made from nitrile rubber with a stainless steel bearing.

This dust cap and plug has a 3/8-inch body size and is made from nitrile rubber with a stainless steel bearing.

This plug has a 4350 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 1/8-inch NPTF connection. This stainless steel plug has a Viton seal.

This plug has a 4350 PSI maximum working pressure and a -40 Degrees F to 158 Degrees F temperature range. This plug features a poppet valve and a 1/8-inch NPTF connection. This stainless steel plug has a Viton seal.

This C200 series quick coupling has a poppet-style valve, a 4640 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 1/2-inch NPTF female pipe connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This C200 series quick coupling has a poppet-style valve, a 4640 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 1/2-inch NPTF female pipe connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This C200 series quick coupling has a poppet-style valve, a 5075 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 3/8-inch NPTF female pipe connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This C200 series quick coupling has a poppet-style valve, a 5075 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 3/8-inch NPTF female pipe connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 1/2-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This quick coupling has a poppet-style valve, a 4350 PSI maximum working pressure, a -40 Degrees F to 158 Degrees F temperature range, and a 1/2-inch NPTF connection. This coupling is made from steel, with a zinc-plated finish and a stainless steel bearing. The seal is made from Buna-N.

This quick coupling has a poppet-style valve, a 3045 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 1/8-inch NPTF connection. This coupling is made from brass, with a stainless steel bearing and a Viton seal.

This quick coupling has a poppet-style valve, a 3045 PSI maximum working pressure, a -4 Degrees F to 392 Degrees F temperature range, and a 1/8-inch NPTF connection. This coupling is made from brass, with a stainless steel bearing and a Viton seal.
