ELECTRIC CHAIN HOIST, 1.5 TON CAPACITY, 15 FT LIFT, 575V, 20/5FPM, 20 IN BETWEEN HOOKS, YLW

ELECTRIC CHAIN HOIST, 1.5 TON CAPACITY, 15 FT LIFT, 575V, 20/5FPM, 20 IN BETWEEN HOOKS, YLW

KITO

ELECTRIC CHAIN HOIST, 1.5 TON CAPACITY, 15 FT LIFT, 575V, 20/5FPM, 20 IN BETWEEN HOOKS, YLW close
close x

images.360.info.textHead1 360° images.360.info.textHead2

  1. Rotate: Use top-to-bottom, side-to-side by use of mouse arrow.
  2. Zoom In: Double click on image.
  3. Zoom Out/Reset: Put photo at full zoom & then double click.
Roll over image to zoom.
Available only while supplies last. Quantities may be limited. The Item is FINAL SALE.
ELECTRIC CHAIN HOIST, 1.5 TON CAPACITY, 15 FT LIFT, 575V, 20/5FPM, 20 IN BETWEEN HOOKS, YLW

ELECTRIC CHAIN HOIST, 1.5 TON CAPACITY, 15 FT LIFT, 575V, 20/5FPM, 20 IN BETWEEN HOOKS, YLW

KITO

Web Price If you have a User ID, sign in to view your account pricing. Your price may be different from the price displayed. : $7,531.42 / EACH

EHC: EHC :
This item requires special shipping, additional charges may apply.

Compliance and Restrictions

  • None

Availability
Availability
Availability Service is temporarily down Available for pickup on: To view Availability, please select a Branch
Availability Service is temporarily down Expected to arrive on: To view Availability for another location, please enter postal code below Availability dates may vary based on the assortment of product in the cart and is not final until you complete your order.
Select a Branch

Selected Branch


Cancel
Please select pick up location
Postal Code should be in LNLNLN format e.g. L3T7W8
Apply
https://catalogue.grainger.ca/?hybris=true
  • Item # KTOER2015SD5-15
  • Mfr. Model # ER2015SD5-15
  • UNSPSC # 24101602
  • CATALOGUE PAGE # N/A
  • Shipping Weight 185.0 lbs

Product Details

This yellow electric chain hoist has a load capacity of 1.5 tons. It can lift to 15 feet, has two speeds of 20 and five feet per minute, and is 575 volts. This chain hoist has thermal protection, 4.8 amps, and 2.4 horsepower. It has a push-button pendant control. The minimum between hooks is 20 inches. This three-phase chain hoist meets ASME and CSA standards.

Technical Specs

  • ItemElectric Chain Hoist
  • Mount TypeHook
  • Number of Speeds2
  • Maximum Lift Speed19 ft/min
  • Maximum Lifting Length15 ft
  • Current at Max. Voltage3.2 A
  • Headroom20 in
  • Brake TypeElectromagnetic Brake
  • Chain GradeGrade 80
  • Chain MaterialAlloy Steel
  • ColourBlack, Yellow
  • FeaturesMaintenance-Free Braking System with A 10-Year/2,000,000 Activation Cycle Warranty
  • Included ComponentsHooks, Load Chain
  • Lifting Hook MaterialCarbon Steel
  • Lifting Hook TypeSwivel Hook with Safety Latch
  • Overload Protection IncludedYes
  • Thermal ProtectionYes
  • Body FinishPowder Coated
  • Mfr. Warranty Length3 yr
  • Duty Classification H4
  • Maximum Lifting Capacity 1 1/2 ton
  • Minimum Lift Speed 5 ft/min
  • Trolley Speed Hook Mounted - No Trolley
  • Current at Min. Voltage 2 A
  • Motor Horsepower 2.4 hp
  • Body Material Aluminum
  • Includes Brake Yes
  • Chain Length 15 ft.
  • Clutch Type Friction Clutch
  • Controls Push Button
  • Hoist IP Rating IP55, IP65
  • Includes Clutch Yes
  • Lifting Hook Opening Width 34 mm
  • Number of Load Chains 1
  • Phase Three
  • Trolley Wheel Material Case-Hardened Steel
  • Chain Finish Nickel Plated
  • Standards ASME B30.16, ASME H4, CSA, IP55
  • Country of Origin Japan (subject to change)
